Microsoft Active Directory

Overview

Microsoft Active Directory (AD) is a directory service developed by Microsoft for Windows domain networks. It provides central authentication and authorization for users, computers, and other resources in an on-premise environment. Integrating Active Directory with Sekoia.io allows for the synchronization of users to enhance security analysis and alert context.

  • Vendor: Microsoft
  • Product: Microsoft Active Directory
  • Supported environment: On-premise

Configure

Prerequisites

To connect your on-premise Active Directory to Sekoia.io, ensure the following requirements are met:

  1. Service Account: A dedicated service account with read-only permissions.

    Recommended: Create a least-privilege account

    Instead of using an admin account, create a dedicated service account with minimal permissions:

    1. Open Active Directory Users and Computers
    2. Create a new user account (e.g., svc-sekoia-sync)
    3. Right-click on the OU containing your users → Delegate Control
    4. Add the service account and select Read all user information
    5. Apply to the relevant OUs containing users

    This account only needs:

    • Read permissions on the Users container (or specific OUs)
    • Read All Properties on User objects
    • No write, delete, or modify permissions

  2. Network Connectivity: Ensure port 636 (LDAPS) is open between your network and the Sekoia.io ingestion point to allow secure communication.

Create connector configuration

This connector utilizes the LDAPS (LDAP over SSL/TLS) protocol to ensure that your credentials and directory data remain encrypted during transit.

A key requirement for this configuration is the Base DN, which defines the starting point for the directory search.

  • Base DN: This identifies the specific container or domain level where the connector starts looking for users.

Example: OU=Users,DC=company,DC=com

Warning

Ensure that the account used has a password that does not expire, or remember to update the connector settings in Sekoia.io whenever the password is changed, otherwise the synchronization will fail.

Create your asset

To start getting your Microsoft Active Directory users into Sekoia.io, you need to create an asset connector on the Assets page. To do so, follow these steps:

  1. Click the Asset connectors button to create a new connector.

    Asset connectors button highlighted

  2. Click the + New connector button.

    New connector button highlighted

  3. Choose Fetch user assets from Microsoft Active Directory, give it a name, and fill the required fields:

    Microsoft Active Directory User connector configuration form

  4. Enter the following information:

    • Servername: The FQDN (Fully Qualified Domain Name) or static IP address of your Active Directory server
    • Admin Username: The username of the account used for the bind.
    • Admin Password: The password associated with the account.

  5. Test the connection by clicking the Test connector button.

    Connector test result and Create asset connector button highlighted

  6. Click the Create asset connector button.

OCSF Mapping for Microsoft Active Directory Users

OCSF Class: User Inventory Info

Class UID: 5003

Information Collected

The Microsoft Active Directory Users fetches comprehensive information and transforms it into the OCSF (Open Cybersecurity Schema Framework) format for standardized security monitoring and asset management.

API Response Examples

Active Directory Active User

Active Directory user with console access and group membership

{
  "objectSid": "S-1-5-21-3623811015-3361044348-30300820-1013",
  "userPrincipalName": "mary.jones@example.com",
  "displayName": "Mary Jones",
  "givenName": "Mary",
  "sn": "Jones",
  "mail": "mary.jones@example.com",
  "objectGUID": "a1b2c3d4-e5f6-7890-abcd-ef1234567890",
  "userAccountControl": 512,
  "memberOf": [
    "CN=Finance Users,OU=Groups,DC=example,DC=com",
    "CN=All Users,OU=Groups,DC=example,DC=com"
  ],
  "department": "Finance",
  "title": "Financial Analyst",
  "employeeID": "EMP456",
  "physicalDeliveryOfficeName": "New York, NY",
  "mobile": "+1-555-234-5678",
  "telephoneNumber": "+1-555-234-5678",
  "distinguishedName": "CN=mary.jones,OU=Users,DC=example,DC=com",
  "whenCreated": "20200604100000.0Z",
  "whenChanged": "20250826093000.0Z",
  "lastLogonTimestamp": "20250826093000.0Z",
  "pwdLastSet": "20250101110000.0Z",
  "accountExpires": "0",
  "lastLogon": "20250826093000.0Z",
  "badPwdCount": 0,
  "logonCount": 156
}

Active Directory Disabled User

Active Directory user with account disabled and expired

{
  "objectSid": "S-1-5-21-3623811015-3361044348-30300820-1014",
  "userPrincipalName": "robert.smith@example.com",
  "displayName": "Robert Smith",
  "givenName": "Robert",
  "sn": "Smith",
  "mail": "robert.smith@example.com",
  "objectGUID": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
  "userAccountControl": 514,
  "memberOf": [
    "CN=Engineering Users,OU=Groups,DC=example,DC=com"
  ],
  "department": "Engineering",
  "title": "Senior Software Engineer",
  "employeeID": "EMP789",
  "physicalDeliveryOfficeName": "San Francisco, CA",
  "mobile": "+1-555-345-6789",
  "telephoneNumber": "+1-555-345-6789",
  "distinguishedName": "CN=robert.smith,OU=Users,DC=example,DC=com",
  "whenCreated": "20200604100000.0Z",
  "whenChanged": "20250818150000.0Z",
  "lastLogonTimestamp": "20250610140000.0Z",
  "pwdLastSet": "20210101120000.0Z",
  "accountExpires": "20240826150000.0Z",
  "lastLogon": "20250610140000.0Z",
  "badPwdCount": 3,
  "logonCount": 89
}

Data Mapping Table

The following table shows how source data is mapped to OCSF model fields:

Source Field OCSF Field Path Description Data Type Logic
objectSid user.uid Active Directory user unique identifier (SID) string Direct mapping of user SID (Security Identifier)
displayName user.name User display name string Direct mapping of display name
displayName user.full_name User full name (from display name) string Direct mapping of display name as full name
distinguishedName user.account.uid Active Directory user DN (Distinguished Name) string Direct mapping of distinguished name
userPrincipalName user.account.name User principal name (UPN) string Direct mapping of user principal name
static: LDAP user.account.type Account type identifier string Always 'LDAP'
static: 4000 user.account.type_id OCSF account type ID integer Always 4000 for LDAP account type
userAccountControl user.is_enabled Whether user account is enabled boolean Compute account enabled status; enabled = not (userAccountControl & 2)
memberOf | length > 0 user.has_groups Whether user belongs to any groups boolean true if user is member of any group, false otherwise
memberOf user.groups Group memberships array[object] Extract group DNs; create Group objects with DN as uid and parsed CN as name
mail user.email_addr User email address string Direct mapping of email address
department user.department User department string Direct mapping of department attribute
title user.job_title User job title string Direct mapping of job title
employeeID user.employee_id Employee ID string Direct mapping of employee ID
physicalDeliveryOfficeName user.office_location Office location string Direct mapping of office location
mobile user.phone Mobile phone number string Direct mapping of mobile phone number
telephoneNumber user.work_phone Work phone number string Direct mapping of work telephone number
objectGUID user.uid_alt Active Directory user GUID (alternative UID) string Direct mapping of GUID; remove curly braces
distinguishedName user.domain User domain extracted from DN string Extract domain from DN; parse DC= components into domain format
whenCreated user.created_time User creation timestamp (Unix epoch) integer Convert LDAP generalized time (YYYYMMDDhhmmss.0Z) to Unix timestamp
whenChanged user.updated_time Last change timestamp (Unix epoch) integer Convert LDAP generalized time to Unix timestamp
lastLogonTimestamp user.last_login_time Last logon timestamp (Unix epoch) integer Convert LDAP generalized time to Unix timestamp
pwdLastSet user.password_last_changed_time Password last changed timestamp (Unix epoch) integer Convert Windows FILETIME to Unix timestamp; return null if 0
accountExpires user.account_expires_time Account expiration timestamp (Unix epoch) integer Convert Windows FILETIME to Unix timestamp; return null if 0 or 9223372036854775807 (never expires)
whenCreated time OCSF event timestamp (user discovery time) integer Convert LDAP generalized time to Unix timestamp for OCSF event timestamp
static: 2 activity_id OCSF activity ID for inventory collection integer Always 2 for 'Collect' activity
static: Collect activity_name OCSF activity name string Always 'Collect'
static: Discovery category_name OCSF category name string Always 'Discovery'
static: 5 category_uid OCSF category UID integer Always 5 for Discovery category
static: User Inventory Info class_name OCSF class name string Always 'User Inventory Info'
static: 5003 class_uid OCSF class UID integer Always 5003 for User Inventory Info
computed: 500300 + activity_id type_uid OCSF type UID integer Base 500300 + activity_id (2 = 500302)
computed: class_name + ': ' + activity_name type_name OCSF type name string Concatenate 'User Inventory Info: Collect'
static: Informational severity Event severity level string Always 'Informational' for inventory events
static: 1 severity_id OCSF severity ID integer Always 1 for Informational severity
static: Microsoft Active Directory metadata.product.name Source product name string Always 'Microsoft Active Directory'
static: 1.6.0 metadata.version OCSF schema version string Fixed OCSF schema version
userAccountControl enrichments[0].data.is_enabled Whether user account is enabled boolean Compute account enabled status; enabled = not (userAccountControl & 2)
lastLogon enrichments[0].data.last_logon Last logon timestamp (Unix epoch) integer Convert lastLogon datetime to Unix timestamp; return null if year <= 1601 or invalid
badPwdCount enrichments[0].data.bad_password_count Number of failed password attempts integer Direct mapping of bad password attempt count
logonCount enrichments[0].data.number_of_logons Total number of logons integer Direct mapping of logon count
static: login enrichments[0].name Enrichment object name string Always 'login' for user enrichment type
static: account_security enrichments[0].value Enrichment object value string Always 'account_security' for AD user login enrichment

OCSF Model Structure

User Inventory Info: Collect

Transformed AD user to OCSF User Inventory Info event

{
  "activity_id": 2,
  "activity_name": "Collect",
  "category_name": "Discovery",
  "category_uid": 5,
  "class_name": "User Inventory Info",
  "class_uid": 5003,
  "type_name": "User Inventory Info: Collect",
  "type_uid": 500302,
  "severity": "Informational",
  "severity_id": 1,
  "time": 1591234567,
  "metadata": {
    "product": {
      "name": "Microsoft Active Directory"
    },
    "version": "1.6.0"
  },
  "user": {
    "uid": "S-1-5-21-3623811015-3361044348-30300820-1013",
    "name": "Mary Jones",
    "full_name": "Mary Jones",
    "email_addr": "mary.jones@example.com",
    "is_enabled": true,
    "domain": "example.com",
    "department": "Finance",
    "job_title": "Financial Analyst",
    "employee_id": "EMP456",
    "office_location": "New York, NY",
    "phone": "+1-555-234-5678",
    "work_phone": "+1-555-234-5678",
    "created_time": 1591234567,
    "updated_time": 1691234000,
    "last_login_time": 1691230000,
    "password_last_changed_time": 1681234567,
    "has_groups": true,
    "account": {
      "uid": "CN=mary.jones,OU=Users,DC=example,DC=com",
      "name": "mary.jones@example.com",
      "type": "LDAP",
      "type_id": 4000
    },
    "groups": [
      {
        "uid": "CN=Finance Users,OU=Groups,DC=example,DC=com",
        "name": "Finance Users"
      }
    ],
    "uid_alt": "a1b2c3d4-e5f6-7890-abcd-ef1234567890"
  },
  "enrichments": [
    {
      "name": "login",
      "value": "account_security",
      "data": {
        "is_enabled": true,
        "last_logon": 1691230000,
        "bad_password_count": 0,
        "number_of_logons": 156
      }
    }
  ]
}
